Siemens siprotec 7SA6 User Manual

Installation and Commissioning
8-30 7SA6 Manual
C53000-G1176-C133-1
1
) Factory settings for devices with power supply voltages of 24 VDC to 125 VDC
2
) Factory settings for devices with power supply voltages of 110 VDC to 220 VDC and 115 VAC
1
) Factory settings for devices with power supply voltages of 24 VDC to 125 VDC
2
) Factory settings for devices with power supply voltages of 110 VDC to 220 VDC and 115 VAC
Table 8-17 Jumper setting of control voltages of the binary inputs BI8 and BI20 on the
binary input/output boards B–I/O–2 for version 7SA6*1–B...
Binary inputs
Jumper
Threshold 17 V
1
) Threshold 73 V
2
)
Slot 19
BI8 X21 1–2 2–3
BI9 X22 1–2 2–3
BI10 X23 1–2 2–3
BI11 X24 1–2 2–3
BI12 X25 1–2 2–3
BI13 X26 1–2 2–3
BI14 X27 1–2 2–3
BI15 X28 1–2 2–3
BI16 X29 1–2 2–3
BI17 X30 1–2 2–3
BI18 X31 1–2 2–3
BI19 X32 1–2 2–3
BI20 X33 1–2 2–3
Table 8-18 Jumper setting of control voltages of the binary inputs BI8 and BI33 on the
binary input/output boards B–I/O–2 for version 7SA6*2–C...
Binary inputs
Jumper
Threshold 17 V
1
) Threshold 73 V
2
)
Slot 33 left Slot 19 right
BI8 BE21 X21 1–2 2–3
BI9 BE22 X22 1–2 2–3
BI10 BE23 X23 1–2 2–3
BI11 BE24 X24 1–2 2–3
BI12 BE25 X25 1–2 2–3
BI13 BE26 X26 1–2 2–3
BI14 BE27 X27 1–2 2–3
BI15 BE28 X28 1–2 2–3
BI16 BE29 X29 1–2 2–3
BI17 BE30 X30 1–2 2–3
BI18 BE31 X31 1–2 2–3
BI19 BE32 X32 1–2 2–3
BI20 BE33 X33 1–2 2–3
