Technical Data
10-44 7SA6 Manual
C53000-G1176-C133-1
Housing for Panel
Surface Mounting
(Size
1
/
1
)
Figure 10-12 Dimensions 7SA6 for panel surface mounting (size
1
/
1
x 19”)
280 (11.02)
465 (18.31)
444 (17.48)
450 (17.72)
320 (12.60) 344 (13.54)
10.5
Front view
1
50
51
100
200
101
151
150
Dimensions in mm
Values in brackets in inches
260 (10.24)
29.5
71
72 52
25
266 (10.47)
Side view
(1.16)
(2.80)
(2.83) 2.05)
(0.98)
9
(0.35)
(0.41)
