Siemens siprotec 7SA6 User Manual

Technical Data
10-457SA6 Manual
C53000-G1176-C133-1
Housing for
Mounting with
Detached
Operator Panel
(Size
1
/
2
x 19”)
Figure 10-13 Dimensions 7SA6 for mounting with detached operator panel (size
1
/
2
x 19”)
244 (9.61)
266 (10.47)
209.5 (8.25)
Mounting plate
225 (8.86)
220 (8.66)
Side view (with screw terminals) Side view
12.5 (0.49)
4.5 (0.18)
312.8 (12.31)
Mounting Holes of
300
±
0.3
(11.81
± 0.01
)
200
± 0.3
(7.87
± 0.11)
34 (1.34)
Dimensions in mm
244 (9.61)
266 (10.47)
209.5 (8.25) 29
Mounting plate
Side view (with plug-in terminals)
30
312.8 (12.31)
34
Values in brackets in inches
Mounting Plate
(1.14)
(1.18)
(1.34)
100
± 0.3
(3.93
± 0.11)
6.4 (0.25)
