Appendix
A-77SA6 Manual
C53000-G1176-C133-1
Region-Specific Default/Language Settings and Function Versions
Region GE, language German (language can be changed) A
Region world, language English (GB) (language can be changed) B
Region US, language English (USA) (language can be changed) C
Region world, language German (language cannot be changed) M
Region world, 50/60 Hz, IEC/ANSI, language English (GB) (language cannot be changed) N
Region US, 60 Hz, ANSI, language English (USA) (language cannot be changed) P
Regulations
on region-specific presettings and function versions:
Region US and World: Stub bus DT visible by other kind of protection function
Region GE: Stub bus DT not visible by other kind of protection function; no ANSI; no miles
Region US: f = 60 Hz; only ANSI-curves; fault detector preset to miles
Port B: Function and Hardware
None 0
System port, IEC protocol, electrical RS232 1
System port, IEC protocol, electrical RS485 2
System port, IEC protocol, optical 820 nm, ST-connector 3
System port, Profibus FMS Slave, electrical RS485 4
System port, Profibus FMS Slave, optical, single-ended ring, ST-connector 5
System port, Profibus FMS Slave, optical, double-ended ring, ST-connector 6
Analog Output 2 x 0 to 20 mA 7
Port C
DIGSI 4, electrical RS232 1
DIGSI 4, electrical RS485 2
With Analog Output see addtional information “M” 9
Port C and Port D
DIGSI 4, electrical RS232 (Port C) 1
DIGSI 4, electrical RS485 (Port C) 2
Analog Output 2 x 0 to 20 mA (Port D) K
see page A-8
_
7SA6
7 8 13 15 1614
_
9101112
Distance Protection (position 10 to 12)
6
5
M+
