Siemens siprotec 7SA6 User Manual

Appendix
A-8 7SA6 Manual
C53000-G1176-C133-1
Functions 1
Only three-pole tripping without overload protection without BCD-output fault location 0
Only three-pole tripping without overload protection with BCD-output fault location 1
Only three-pole tripping with overload protection without BCD-output fault location 2
Only three-pole tripping with overload protection with BCD-output fault location 3
Single-/three-pole tripping without overload protection without BCD-output fault location 4
Single-/three-pole tripping without overload protection with BCD-output fault location 5
Single-/three-pole tripping with overload protection without BCD-output fault location 6
Single-/three-pole tripping with overload protection with BCD-output fault location 7
Functions 2
Pickup I> without power swing option without parallel line compensation A
Pickup U,I without power swing option without parallel line compensation B
Pickup Z<, Polygon without power swing option without parallel line compensation C
Pickup Z<, Polygon, U, I, ϕ without power swing option without parallel line compensation D
Pickup Z<, Polygon with power swing option without parallel line compensation F
Pickup Z<, Polygon, U, I, ϕ with power swing option without parallel line compensation G
Pickup U,I without power swing option with parallel line compensation
2
)J
Pickup Z<, Polygon without power swing option with parallel line compensation
2
)K
Pickup Z<, Polygon, U, I, ϕ without power swing option with parallel line compensation
2
) L
Pickup Z<, Polygon with power swing option with parallel line compensation
2
) N
Pickup Z<, Polygon, U, I, ϕ with power swing option with parallel line compensation
2
)P
Functions 3
Automatic Synchro- Breaker Failure Voltage
Reclosure Check Protection Protection
without without without without A
without without without with B
without without with without C
without without with with D
without with without without E
without with without with F
without with with without G
without with with with H
with without without without J
with without without with K
with without with without L
with without with with M
with with without without N
with with without with P
with with with without Q
with with with with R
Functions 4
Earth Fault Protection / Directional Earth Fault Detection for Measured Values, Extended,
for Earthed Systems Resonant-Earthed / Min/Max Values
Isolated Systems
without without without 0
without without with 1
without with
1
) without 2
without with
1
) with 3
with without without 4
with without with 5
with with
1
) without 6
with with
1
) with 7
1
) only available with „2“ or „6“ on position 7
2
) only available with „1“ or „5“ on position 7
_
7SA6
7 8 13 15 1614
_
9101112
Digital Distance Protection (positon 13 to 16)
