Appendix
B-52
7350 CB-TEST was succesful (CB-TST
.OK.)
Testing OUT_Ev ON *
10201 >BLOCK Uph-e>(>) Overvolt.
(phase-earth) (>Uph-e>(>) BLK)
Voltage Protection SP * * LED BI BO
10202 >BLOCK Uph-ph>(>) Overvolt
(phase-phase) (>Uph-ph>(>) BLK)
Voltage Protection SP * * LED BI BO
10203 >BLOCK 3U0>(>) Overvolt. (zero
sequence) (>3U0>(>) BLK)
Voltage Protection SP * * LED BI BO
10204 >BLOCK U1>(>) Overvolt. (positive
seq.) (>U1>(>) BLK)
Voltage Protection SP * * LED BI BO
10205 >BLOCK U2>(>) Overvolt. (negative
seq.) (>U2>(>) BLK)
Voltage Protection SP * * LED BI BO
10206 >BLOCK Uph-e<(<) Undervolt
(phase-earth) (>Uph-e<(<) BLK)
Voltage Protection SP * * LED BI BO
10207 >BLOCK Uphph<(<) Undervolt
(phase-phase) (>Uphph<(<) BLK)
Voltage Protection SP * * LED BI BO
10208 >BLOCK U1<(<) Undervolt (positive
seq.) (>U1<(<) BLK)
Voltage Protection SP * * LED BI BO
10215 Uph-e>(>) Overvolt. is switched OFF
(Uph-e>(>) OFF)
Voltage Protection OUT ON
OFF
* LED BO 73 15 1 GI
10216 Uph-e>(>) Overvolt. is BLOCKED
(Uph-e>(>) BLK)
Voltage Protection OUT ON
OFF
ON
OFF
LED BO 73 16 1 GI
10217 Uph-ph>(>) Overvolt. is switched
OFF (Uph-ph>(>) OFF)
Voltage Protection OUT ON
OFF
* LED BO 73 17 1 GI
10218 Uph-ph>(>) Overvolt. is BLOCKED
(Uph-ph>(>) BLK)
Voltage Protection OUT ON
OFF
ON
OFF
LED BO 73 18 1 GI
10219 3U0>(>) Overvolt. is switched OFF
(3U0>(>) OFF)
Voltage Protection OUT ON
OFF
* LED BO 73 19 1 GI
10220 3U0>(>) Overvolt. is BLOCKED
(3U0>(>) BLK)
Voltage Protection OUT ON
OFF
ON
OFF
LED BO 73 20 1 GI
10221 U1>(>) Overvolt. is switched OFF
(U1>(>) OFF)
Voltage Protection OUT ON
OFF
* LED BO 73 21 1 GI
10222 U1>(>) Overvolt. is BLOCKED
(U1>(>) BLK)
Voltage Protection OUT ON
OFF
ON
OFF
LED BO 73 22 1 GI
10223 U2>(>) Overvolt. is switched OFF
(U2>(>) OFF)
Voltage Protection OUT ON
OFF
* LED BO 73 23 1 GI
10224 U2>(>) Overvolt. is BLOCKED
(U2>(>) BLK)
Voltage Protection OUT ON
OFF
ON
OFF
LED BO 73 24 1 GI
10225 Uph-e<(<) Undervolt. is switched
OFF (Uph-e<(<) OFF)
Voltage Protection OUT ON
OFF
* LED BO 73 25 1 GI
10226 Uph-e<(<) Undervolt. is BLOCKED
(Uph-e<(<) BLK)
Voltage Protection OUT ON
OFF
ON
OFF
LED BO 73 26 1 GI
10227 Uph-ph<(<) Undervolt. is switched
OFF (Uph-ph<(<) OFF)
Voltage Protection OUT ON
OFF
* LED BO 73 27 1 GI
10228 Uphph<(<) Undervolt. is BLOCKED
(Uph-ph<(<) BLK)
Voltage Protection OUT ON
OFF
ON
OFF
LED BO 73 28 1 GI
10229 U1<(<) Undervolt. is switched OFF
(U1<(<) OFF)
Voltage Protection OUT ON
OFF
* LED BO 73 29 1 GI
F.No. Description Function Type of
Information
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information-No
Data Unit (ASDU)
General Interrogation
