7191 Backup O/C Pickup I>> (O/C
PICKUP I>>)
Backup overcur-
rent
OUT * ON LED BO 64 91 2 GI
7192 Backup O/C Pickup I> (O/C PICKUP
I>)
Backup overcur-
rent
OUT * ON LED BO 64 92 2 GI
7193 Backup O/C Pickup Ip (O/C PICKUP
Ip)
Backup overcur-
rent
OUT * ON LED BO 64 93 2 GI
7201 O/C I-STUB Pickup (I-STUB
PIKKUP)
Backup overcur-
rent
OUT * ON
OFF
LED BO 64 101 2 GI
7211 Backup O/C General TRIP com-
mand (O/C TRIP)
Backup overcur-
rent
OUT * * LED BO 64 111 2
7212 Backup O/C TRIP - Only L1 (O/C
TRIP 1p.L1)
Backup overcur-
rent
OUT * ON LED BO 64 112 2
7213 Backup O/C TRIP - Only L2 (O/C
TRIP 1p.L2)
Backup overcur-
rent
OUT * ON LED BO 64 113 2
7214 Backup O/C TRIP - Only L3 (O/C
TRIP 1p.L3)
Backup overcur-
rent
OUT * ON LED BO 64 114 2
7215 Backup O/C TRIP Phases L123 (O/
C TRIP L123)
Backup overcur-
rent
OUT * ON LED BO 64 115 2
7221 Backup O/C TRIP I>> (O/C TRIP
I>>)
Backup overcur-
rent
OUT * ON LED BO 64 121 2
7222 Backup O/C TRIP I> (O/C TRIP I>) Backup overcur-
rent
OUT * ON LED BO 64 122 2
7223 Backup O/C TRIP Ip (O/C TRIP Ip) Backup overcur-
rent
OUT * ON LED BO 64 123 2
7235 O/C I-STUB TRIP (I-STUB TRIP) Backup overcur-
rent
OUT * ON LED BO 64 135 2
7325 CB1-TEST TRIP command - Only
L1 (CB1-TESTtrip L1)
Testing OUT ON
OFF
* LED BO 153 25 2 GI
7326 CB1-TEST TRIP command - Only
L2 (CB1-TESTtrip L2)
Testing OUT ON
OFF
* LED BO 153 26 2 GI
7327 CB1-TEST TRIP command - Only
L3 (CB1-TESTtrip L3)
Testing OUT ON
OFF
* LED BO 153 27 2 GI
7328 CB1-TEST TRIP command L123
(CB1-TESTtrip123)
Testing OUT ON
OFF
* LED BO 153 28 2 GI
7329 CB1-TEST CLOSE command (CB1-
TEST close)
Testing OUT ON
OFF
* LED BO 153 29 2 GI
7345 CB-TEST is in progress (CB-TEST
running)
Testing OUT ON
OFF
* LED BO 153 45 2 GI
7346 CB-TEST canceled due to Power
Sys. Fault (CB-TSTstop FLT.)
Testing OUT_Ev ON *
7347 CB-TEST canceled due to CB
already OPEN (CB-TSTstop OPEN)
Testing OUT_Ev ON *
7348 CB-TEST canceled due to CB was
NOT READY (CB-TSTstop NOTr)
Testing OUT_Ev ON *
7349 CB-TEST canceled due to CB
stayed CLOSED (CB-TSTstop
CLOS)
Testing OUT_Ev ON *
F.No. Description Function Type of
Information
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information-No
Data Unit (ASDU)
General Interrogation
