10282 U1> TimeOut (U1> TimeOut) Voltage Protection OUT * * LED BO
10283 U1>> TimeOut (U1>> TimeOut) Voltage Protection OUT * * LED BO
10284 U1>(>) TRIP command (U1>(>)
TRIP)
Voltage Protection OUT * ON LED BO 73 84 2 GI
10290 U2> Pickup (U2> Pickup) Voltage Protection OUT * ON
OFF
LED BO 73 90 2 GI
10291 U2>> Pickup (U2>> Pickup) Voltage Protection OUT * ON
OFF
LED BO 73 91 2 GI
10292 U2> TimeOut (U2> TimeOut) Voltage Protection OUT * * LED BO
10293 U2>> TimeOut (U2>> TimeOut) Voltage Protection OUT * * LED BO
10294 U2>(>) TRIP command (U2>(>)
TRIP)
Voltage Protection OUT * ON LED BO 73 94 2 GI
10300 U1< Pickup (U1< Pickup) Voltage Protection OUT * ON
OFF
LED BO 73 100 2 GI
10301 U1<< Pickup (U1<< Pickup) Voltage Protection OUT * ON
OFF
LED BO 73 101 2 GI
10302 U1< TimeOut (U1< TimeOut) Voltage Protection OUT * * LED BO
10303 U1<< TimeOut (U1<< TimeOut) Voltage Protection OUT * * LED BO
10304 U1<(<) TRIP command (U1<(<)
TRIP)
Voltage Protection OUT * ON LED BO 73 104 2 GI
10310 Uph-e< Pickup (Uph-e< Pickup) Voltage Protection OUT * ON
OFF
LED BO 73 110 2 GI
10311 Uph-e<< Pickup (Uph-e<< Pickup) Voltage Protection OUT * ON
OFF
LED BO 73 111 2 GI
10312 Uph-e<(<) Pickup L1 (Uph-e<(<) PU
L1)
Voltage Protection OUT * ON
OFF
LED BO 73 112 2 GI
10313 Uph-e<(<) Pickup L2 (Uph-e<(<) PU
L2)
Voltage Protection OUT * ON
OFF
LED BO 73 113 2 GI
10314 Uph-e<(<) Pickup L3 (Uph-e<(<) PU
L3)
Voltage Protection OUT * ON
OFF
LED BO 73 114 2 GI
10315 Uph-e< TimeOut (Uph-e< TimeOut) Voltage Protection OUT * * LED BO
10316 Uph-e<< TimeOut (Uph-e<< Time-
Out)
Voltage Protection OUT * * LED BO
10317 Uph-e<(<) TRIP command (Uph-
e<(<) TRIP)
Voltage Protection OUT * ON LED BO 73 117 2 GI
10325 Uph-ph< Pickup (Uph-ph< Pickup) Voltage Protection OUT * ON
OFF
LED BO 73 125 2 GI
10326 Uph-ph<< Pickup (Uph-ph<<
Pickup)
Voltage Protection OUT * ON
OFF
LED BO 73 126 2 GI
10327 Uphph<(<) Pickup L1-L2
(Uphph<(<)PU L12)
Voltage Protection OUT * ON
OFF
LED BO 73 127 2 GI
10328 Uphph<(<) Pickup L2-L3
(Uphph<(<)PU L23)
Voltage Protection OUT * ON
OFF
LED BO 73 128 2 GI
10329 Uphph<(<) Pickup L3-L1
(Uphph<(<)PU L31)
Voltage Protection OUT * ON
OFF
LED BO 73 129 2 GI
10330 Uphph< TimeOut (Uphph< TimeOut) Voltage Protection OUT * * LED BO
F.No. Description Function Type of
Information
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information-No
Data Unit (ASDU)
General Interrogation
