Siemens siprotec 7SA6 User Manual

Appendix
B-56
Disconnect Switch (Disc.Swit.) Control Device DP on
off
* BI CB 240 161 1 GI
Earth Switch (EarthSwit) Control Device CF_D2 on
off
* BO 240 164 1 GI
Earth Switch (EarthSwit) Control Device DP on
off
* BI CB 240 164 1 GI
Fan ON/OFF (Fan ON/OFF) Control Device CF_D2 on
off
* BO 240 175 1 GI
Fan ON/OFF (Fan ON/OFF) Control Device DP on
off
* BI CB 240 175 1 GI
Fault Recording Start (FltRecSta) Oscillographic
Fault Records
IntSP ON
OFF
* LED BO
Feeder EARTHED (FdrEARTHED) Device IntSP * * LED BO
Group A (Group A) Change Group IntSP ON
OFF
* LED BO 128 23 1 GI
Group B (Group B) Change Group IntSP ON
OFF
* LED BO 128 24 1 GI
Group C (Group C) Change Group IntSP ON
OFF
* LED BO 128 25 1 GI
Group D (Group D) Change Group IntSP ON
OFF
* LED BO 128 26 1 GI
Hardware Test Mode (HWTestMod) Device IntSP ON
OFF
* LED BO
Interlocking: 52 Close (52 Close) Control Device IntSP * *
Interlocking: 52 Open (52 Open) Control Device IntSP * *
Interlocking: Disconnect switch
Close (Disc.Close)
Control Device IntSP * *
Interlocking: Disconnect switch
Open (Disc.Open)
Control Device IntSP * *
Interlocking: Earth switch Close (E
Sw Cl.)
Control Device IntSP * *
Interlocking: Earth switch Open (E
Sw Open)
Control Device IntSP * *
Q2 Open/Close (Q2 Op/Cl) Control Device CF_D2 on
off
* BO 240 162 1 GI
Q2 Open/Close (Q2 Op/Cl) Control Device DP on
off
* BI CB 240 162 1 GI
Q9 Open/Close (Q9 Op/Cl) Control Device CF_D2 on
off
* BO 240 163 1 GI
Q9 Open/Close (Q9 Op/Cl) Control Device DP on
off
* BI CB 240 163 1 GI
Stop data transmission (DataStop) Device IntSP ON
OFF
* LED BO 128 20 1 GI
Test mode (Test mode) Device IntSP ON
OFF
* LED BO 128 21 1 GI
Unlock data transmission via BI
(UnlockDT)
Control Device IntSP * *
F.No. Description Function Type of
Information
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information-No
Data Unit (ASDU)
General Interrogation
