Options
8.3 G20, CBC10 Communication Board
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
351
Damage to or malfunction of Option Boards by pulling and pluging them during operation
Withdrawing and inserting Option Boards during operation can cause them to be damaged
or to malfunction.
• Only pull and plug Option Boards when the Control Unit is current-free.
Note
Additional information
Detailed and comprehensive instructions and information for the CBC10 Communication
Board can be found in the accompanying operating instructions. These operating instructions
are available as additional documentation on the cus
tomer DVD provided.
Figure 8-2 CAN CBC10 Communication Board, interface overview
