Display messages DAC UNIVERSAL
ADVANCED
Should the DAC UNIVERSAL encounter a display message, this will be
shown on the display as seen on the picture. The error symbol is
displayed in the top left corner followed by the code of the concerning
error.
For some display messages that could be easy solvable, by the user,
additional pictograms are shown, to help the user understand the display
message and start troubleshooting.
If the display message is not immediately recognized by the user, the
display message must be located in the list and the appropriate actions
taken, see "Display messages and what they mean DAC UNIVERSAL
ADVANCED [ → 142]".
For display message which have occurred during sterilization an
additional warning symbol is shown.
Reset display messages
IMPORTANT
When the DAC UNIVERSAL shows a display message, a complete
cycle may not have been conducted. The instruments are thus
considered non-sterile and must be reprocessed again.
CAUTION
Danger of burning!
Hot steam may emerge from the chamber.
➢ Please do not open the DAC UNIVERSAL when the temperature is
still above 104°C (219°F), see display indicator.
IMPORTANT
If the DAC UNIVERSAL shows the same display message more than
once, and this is not due to lack of consumables, please contact your
authorized dealer.
IMPORTANT
When an error is encountered, an alarm will sound and the display
message will appear in the display.
➢ Please note the message before resetting the alarm.
➢ Press the "Up"-Key to stop the alarm and return.
 When the "Up"-Key is pressed, the lid is raised in a duration of
approx. 2 seconds. The lid stops until the temperature drops to less
than 104°C / 219°F. Then it opens completely.
