Sirona DAC UNIVERSAL - Attaching Instruments to the Respective STANDARD Lid Adapters; Iso;Intramatic and Osada HL-C Adapter

60 53 362 D3472
220 D3472.201.10.20.02 07.2016
11Accessories Sirona Dental A/S
11.1Adapters for the STANDARD lid Operating Instructions DAC UNIVERSAL
11.1.1 Attaching instruments to the respective STANDARD lid
adapters
11.1.1.1
ISO/INTRAmatic and Osada HL-C adapter
The ISO/INTRAmatic adapter has been shortened to also accommodate
smaller handpieces and the Osada HL-C.
Dealing wi th adapters_Sirona_ Nitram
Follow the general safety information in "General placement of
instruments DAC UNIVERSAL ADVANCED [ → 115]" or "General
placement of instruments DAC UNIVERSAL STANDARD [ → 187]" when
handling the adapters described here.
Attachment
1. Press the straight or contra-angle handpiece onto the adapter until
you hear and feel a slight click.
2. Pull lightly on the straight or contra-angle handpiece to ensure that it
is correctly attached to the adapter.
Removal
1. Press the small button at the bottom of the adapter and
simultaneously detach the straight or contra-angle handpiece.
2. Release the button.
IMPORTANT
When using a straight or contra-angle handpiece with an exchangeable
head, the head must be reprocessed separately. To reprocess the head
use the contra-angle handpiece head adapter, see "Adapter for contra-
angle handpiece head [ → 222]". The instrument (without head) is
reprocessed on the ISO/INTRAmatic adapter.
IMPORTANT
The PCD test device is also reprocessed on the ISO/INTRAmatic
adapter. See "Testing with a PCD process challenge device [ → 64]" for
details.
