5Operation DAC UNIVERSAL ADVANCED Sirona Dental A/S
5.1Regular activities Operating Instructions DAC UNIVERSAL
Replacement of the oil bottle
✔ The lid of the DAC UNIVERSAL water tank is open.
1. Unscrew the empty oil bottle counterclockwise and remove it from the
oil dispenser.
2. Insert the new oil bottle thread down into the thread of the oil
dispenser (next to the water tank).
3. Turn the oil bottle carefully clockwise until you meet resistance.
4. Close the lid of the water tank.
 The oil bottle has been replaced.
Tip: You can also remove a partially used oil bottle that is not yet empty
from the DAC UNIVERSAL and insert it again at a later time.
5.1.4 Pumping lubrication concentrate through the system
When a new bottle of lubrication concentrate has been inserted, you must
check whether oil is pumped into the chamber.
See "Checking oil supply to the chamber of the DAC UNIVERSAL
ADVANCED [ → 122]" for the procedure.
IMPORTANT
The oil bottle must be replaced when the "Low oil" message appears on
the display.
IMPORTANT
If the oil bottle is not completely empty, small quantities of oil may leak
out of the bottle. Wipe the oil away with an absorbent cloth.
