Sirona DAC UNIVERSAL - Adapter for Contra-Angle Handpiece Head

60 53 362 D3472
222 D3472.201.10.20.02 07.2016
11Accessories Sirona Dental A/S
11.1Adapters for the STANDARD lid Operating Instructions DAC UNIVERSAL
11.1.1.3
Adapter for contra-angle handpiece head
For reprocessing KaVo, BienAir, and Osada instruments with removable
heads.
Dealing wi th adapters_Sirona_ Nitram
Follow the general safety information in "General placement of
instruments DAC UNIVERSAL ADVANCED [ → 99]" or "General
placement of instruments DAC UNIVERSAL STANDARD [ → 172]" when
handling the adapters described here.
Attachment
1. Remove the contra-angle handpiece head by twisting the ring on the
handpiece clockwise while pulling the head out.
2. Then press the contra-angle handpiece onto the adapter until you
hear and feel a slight click. When attaching it, make sure the two lugs
at the sides of the contra-angle handpiece head click into the groove
on the adapter.
Removal
➢ Hold the STANDARD lid of the DAC UNIVERSAL firmly with one
hand and simultaneously detach the contra-angle handpiece head.
IMPORTANT
To reprocess the instrument without the head use the ISO/INTRAmatic
adapter, see "ISO/INTRAmatic and Osada HL-C adapter [ → 220]".
