3.2Controls and functional elements of the DAC UNIVERSAL Operating Instructions DAC UNIVERSAL
3.2
Controls and functional elements of the DAC
UNIVERSAL
Display DAC UNIVERSAL ADVANCED
With the DAC UNIVERSAL ADVANCED a new appearance has been
introduced see „Overview DAC UNIVERSAL ADVANCED [ → 26]“.
For an overview of the DAC UNIVERSAL STANDARD see „Overview
DAC UNIVERSAL STANDARD [ → 27]“.
Link_versions of the DAC U.
Please refer to „Versions of the DAC UNIVERSAL [ → 10]“ in order to
differentiate between these versions.
3.2.1 Overview of the DAC UNIVERSAL
3.2.1.1
Overview DAC UNIVERSAL ADVANCED
A Lid
B Lubrication concentrate and oil dispenser
C Water tank
D Display with keyboard
E Safety ring
