Page 79 of 292
Step 3 Connection of Oxygen and Air Hoses to the Gas Supplies
Plug into the gas supplies, at a gas pressure of about 4 bar.
Step 4 Connection of Mains Power
Check that the mains power switch on the ventilator is set to Off (A).
Connect the plug to a suitably rated and grounded mains supply. Turn on the
mains supply (B).
Air outlet
Oxygen outlet
Oxygen supply hose
Air supply hose
Check mains power switch is set to OFF (O)
Connect plug to mains
switch and turn on at
swtich
AB
