Chapter 1 Safety Instructions
HRL Series 1.4 Product Label
1-3
1.4 Product Label
Information about the product, such as Serial No. and Model No. can be
found on the product label. This information is needed when contacting an
SMC sales distributor.
How to see the serial number Z R 001 （APR 2021）
Z
R
001
Year
Symbol
Remarks
Month
Symbol
Remarks
Serial no.
2021
Z
Repeated from
A to Z in
alphabetical
order
1
o
Repeated from
O to Z in alphabetical
order, with O for
January and Z for
December
－
2022
A
2
P
2023
B
3
Q
↓
↓
↓
↓
Fig. 1-1 Position of the product label
* (An example of "HRL200-A-40" model.)
"3~" stands for "3 inter phase".
(IEC 60417-5032-1)
Model number
Serial number
Kind and amount
of refrigerant
