SMC Networks HRL100-A 40 Series User Manual

HRX-OM-X037
Chapter 5 Display and Setting of Various Functions
5.4 Description of the Screen HRL Series
5-14
5.4.2 Menu
[ ] (menu) key is located upper left on the applicable screen.
Touch [ ] key to display the menu. Go to the applicable setting
screen from the menu.
The menu is closed when [ ] key is touched while the menu is
displayed.
5.4.3 Status screen
Press [ ] button on the menu to display “Status” screen.
The screen display of the “Status” screen is shown in Table 5.4-2 Screen
display of status screen.
Applicable screen
Menu
Touch this mark
Touching the
“Menu” closes it.
Press
The “Menu” is closed
when it is touched.
Menu
Press
[Menu] key
[Menu] key
Status screen
(1)
(2)
(3)
(4)
(7)
(8)
(9)
(10)
(11)
(6)
(12)
(13)
(14)
(15)
(5)
