SMC Networks HRL100-A 40 Series User Manual

HRX-OM-X037
Chapter 4 Starting the Product
4.4 Operation Start and Stop HRL Series
4-6
4. Repeat the procedures 1–3 until the fluid level of the product stops dropping.
[Tips]
While the low tank fluid level alarm (AL02/AL04) is still on (without turning off
the alarm), the home screen can be displayed to carry out independent pump
operation. If the fluid level continues to drop, the alarm “AL01 CH1 LOW level
FLT” or “AL03 CH2 LOW level FLT” is activated.
4.4 Operation Start and Stop
4.4.1 Setting of circulating fluid temperature
Press the [SP] value on the touch panel (home screen) to display numeric
keys to set the circulating fluid set temperature. Enter the set temperature for
CH1 and CH2.
Fig. 4-8 Setting of CH1 circulating fluid temperature
Touch this mark
Enter a value
Value shown in orange
Numeric keys
