Chapter 3 Transport and Setting Up
HRL Series 3.3 Installation
3-25
3.3.7 Wiring of analog output signal
This product can send output analog signals.
The analog output signal and the factory settings are as follows:
The signal content can be selected from four types. Refer to “5.4.10Communication
setting screen”
Table 3.3-6 Analog output signal
No.
Signal item
Output voltage
Default setting
1
CH2 circulating fluid
temperature
0.0 to 100.0 °C：0.00 to 10.00V
Analog output 1
2
CH2 electric conductivity
0.1 to 50.0μS/cm：0.02 to 10.00V
Analog output 2
3
CH1 circulating fluid
temperature
0.0 to 100.0 °C：0.00 to 10.00V
－
4
CH1 electric conductivity
0.1 to 50.0μS/cm：0.02 to 10.00V
－
3.3.8 RS-485 communication wiring
This product can operate the following by serial communication RS-485.
-Control of Run/Stop
-Circulating fluid temperature setting
-Circulating fluid temperature reading
-Operation status reading
-Alarm condition reading
Refer to Operation Manual Communication Function for more details.
 RS-485 communication connector
The following connector is used for this product as a connector for RS – 485
communication. Please prepare suitable mating connector.
Table 3.3-7 RS-485 communication connector
Connector specification
Dsub 9 pin female (socket) type
Be sure to turn OFF the breaker of the facility power supply (the user's
machine power supply) before wiring.
