Chapter 3 Transport and Setting Up
3.2 Installation HRL Series
3-4
3.2 Installation
3.2.1 Environment
The product must not be operated, installed, stored or transported in the following conditions.
Potential malfunction or damage to the product may occur if these instructions are
disregarded.
This product is not designed for clean room usage. The pump and ventilating fan inside the
product generate particles.
● Location that is outside.
● Location that is exposed to steam, salt water or oil.
● Location that is exposed to dust or powder material.
● Location that is exposed to corrosive gas, organic solvent, chemical solution, or
flammable gas. (The product is not explosion-proof.)
● Location where the ambient temperature is out of the following range:
During transportation or storage: -15 to 50°C (No water or circulating fluid in the
piping.)
During operation : 2 to 45°C
● Location where condensation forms on the inside electrical parts.
● Location that is exposed to direct sunlight or heat radiation
● Location that is near heat sources and poor in ventilation.
● Location that is subjected to abrupt changes in temperature.
● Location that is subjected to strong electromagnetic noise (intense electric field,
intense magnetic field, or surges).
● Location that is subjected to static electricity, or conditions where static electricity can
discharge to the product.
● Location that is subjected to strong high frequencies raditation.
● Location that is subjected to potential lightening strike.
● Location at an altitude of 3000m or higher (except during product storage and
transportation).Refer to the next page for details.
● Location where the product is affected by strong vibrations or impacts.
● Condition that applies external force or weight causing the product to be damaged.
● Location without adequate space for maintenance as required.
● For the product installation or operation in accordance with UL standards, see below.
 Do not set up the product in exposed locations where there is a risk
offlammable gas. Should any flammable gas remain around the
product, the product may cause a fire.
 Keep the product upright on a rigid and flat floor which can resist the
weight of the product. Take measures to prevent the product from
tipping over. Improper installation may cause water leakage, tipping,
damage of the product or injure the operator.
 Keep the ambient temperature of the product between 2 to 45
o
C.
Operation out of this ambient temperature range may cause a product
malfunction. Operating the product in an environment temperature of
45
o
C may reduce the heat discharging efficiency of the heat
exchanger and the safety device may function, resulting in the
stoppage of the product operation.
 Following the installation, The installer/end user is responsible for
performing an acoustic noise risk assessment on the equipment and
taking appropriate measures as required.
