Chapter 5 Display and Setting of Various Functions
5.4 Description of the Screen HRL Series
5-60
Table 5.4-29 Setting of contact output signal 4 to 6
No.
Indication
Item
Signal type
Contact type
(1)
Output 4
Function
Contact output
signal 4
Select from “Table
5.4-29 Signal type for
contact output signal
4 to 6”  [OFF]

A contact (normally open)
B contact
(normally closed)
(2)
Output 5
Function
Contact output
signal 5

A contact (normally open)
B contact
(normally closed)
(3)
Output 6
Function
Contact output
signal 6

A contact (normally open)
B contact
(normally closed)
By default
Setting of contact output signal 4 to 6
(1)
(2)
(3)
Selection of signal type
