HRX-OM-X037
Chapter 9 Documents
9.4 Cooling Capacity HRL Series
9-14
9.4.5 HRL100-A-40-T2 CH1
Fig. 9-11 Cooling Capacity (HRL100-A-40-T2 CH1)
9.4.6 HRL200-A-40-T2 CH2
Fig. 9-12 Cooling Capacity (HRL200-A-40-T2 CH1)
This is the cooling capacity of the CH1 side when 1 Kw
heat load is applied to the CH2 side.
This is the cooling capacity of the CH1 side when 1 Kw
heat load is applied to the CH2 side.
0
5
10
15
20
25
30
0 5 10 15 20 25 30 35 40
Cooling capacity [kW]
Circulating fluid temperature [
o
C]
Ambienttemperature
32
o
C
45
o
C
0
2
4
6
8
10
12
14
0 5 10 15 20 25 30 35 40
Cooling capacity [kW]
Circulating fluid temperature [
o
C]
Ambienttemperature
32
o
C
45
o
C
