HRX-OM-X037
Chapter 3 Transport and Setting Up
HRL Series 3.1 Transport
3-3
3.1.2 Transportation using casters
Fig. 3-2 Transportation using casters
Raise the adjuster
foot.
Swivel
caster
Each swivel caster can
rotate 360 degrees freely.
Raise the adjuster feet and push the corners of the product when
moving the product using the casters.
Do not hold the piping connections or handles of the panels when
moving by casters, or it may cause damage to the product..
This is a heavy product. (Refer to Table 3.1-1 Weight of the product).
Moving the product by casters should be done by 2 persons or more.
