HRX-OM-X037
Chapter 4 Starting the Product
HRL Series 4.4 Operation Start and Stop
4-9
4.5 Check Items during Startup
Check the following items after starting the product.
 Confirm that there is leakage from the piping.
 Confirm that no circulating fluid is discharged from the tank drain
port.
 Confirm that the circulating fluid pressure is within the specification
range.
 The fluid level is within the range.
4.6 Adjusting the Circulating Fluid Flow Rate
If the circulating fluid flow rate is smaller than the minimum required, the
product may fail to maintain performance, making it impossible for the
compressor to operate. Refer to Figure 3-17 to find the recommended piping
circuit fluid flow rate for adjustment, and adjust the manual valve while
monitoring the pressure and flow rate of the user’s equipment to achieve the
required pressure or flow rate.
[Tips]
Refer to “9.1 Specifications” for the minimum required flow rate.
If abnormality is detected, press [ ] key and turn OFF the
facility power supply (power supply of the user’s equipment) breaker.
