HRL Series 9.1 Specifications
9-1
Chapter 9 Documents
9.1 Specifications
9.1.1 HRL100/200/300-A-40
Table 9.1-1 Specifications
Model
HRL100-A-40
HRL200-A-40
HRL300-A-40
CH1
CH2
CH1
CH2
CH1
CH2
Cooling method
Air-cooled refrigeration
Refrigerant
R410A(HFC)
Quantity of refrigerant
kg
1.4
1.8
2.5
Control method
PID control
Ambient temperature
°C
2 to 45
Circulating
fluid
system
Circulating fluid
CH1 : Clear water 1, DI water (pure water) 9
CH2 : Clear water 1,DI water (pure water)
Set temperature range
°C
CH1 : 5 to 35 / CH2 : 10 to 40
Cooling capacity2
kW
9
1 8
19
1 8
26
1 8
Heating capacity3
kW
1.5
1
4.0
1
6.0
1
Temperature stability 4
°C
CH1 ： ±0.1
CH2 ： ±0.5
Pump
capacity
13
Rated flow rate
(Outlet)
L/min
45
(0.43MPa)
10
(0.45MPa)
45
(0.45MPa)
10
(0.45MPa)
125
(0.45MPa)
10
(0.45MPa)
Maximum flow
rate
L/min
120
16 *12
130
16 *12
180
16 *12
Maximum lifting
height
m
50
49
55
49
68
49
Settable pressure range 5
MPa
0.10
to
0.50
0.10
to
0.49
0.10
to
0.55
0.10
to
0.49
0.10
to
0.68
0.10
to
0.49
Minimum operating flow rate 6
L/min
20
2
25
2
40
2
Tank capacity14
L
42
7
42
7
60
7
By-pass (With valve)
built-in
Electric conductivity
setting range
μS/
cm
0.5 to 45 9
0.5 to 45
0.5 to 45 9
0.5 to 45
0.5 to 45 9
0.5 to 45
Particle filter filtration accuracy
(Accessory)
μm
5
5
5
5
5
5
Circulating fluid outlet,
Circulating fluid return port14
CH1 : Rc1 (Symbol F：G1,Symbol N：NPT1)
CH2 : Rc1/2 (Symbol F：G1/2,Symbol N：NPT1/2)
Tank drain port14
CH1 : Rc3/4 (Symbol F：G3/4,Symbol N：NPT3/4）
CH2 : Rc1/2 (Symbol F：G1/2,Symbol N：NPT1/2）
Wetted material
CH1 : Stainless steel, Copper (Brazing filler metal for the heat exchanger) 10,
Brass 10,Bronze 10,Fluoropolymer,PP,PBT,POM,PU,PC,PVC,
EPDM,NBR, Ion-exchange resin 9
CH2 : Stainless, Alumina ceramic, Carbon, Fluoropolymer,PP,PBT,POM,PU,
PVC,PPS,AS,PS,EPDM,NBR, Ion-exchange resin
Electrical
system
Power supply
3-phase 380 to 415VAC(50/60Hz)
Allowable voltage range ±10%(No continuous voltage fluctuation)
3-phase 460 to 480VAC(60Hz)
Allowable voltage range +4%,-10%(Max. voltage less than 500V and no
continuous voltage fluctuation)
Applicable earth
leakage breaker

Rated
current
A
20
30
40
Sensitivity
current
mA
30
Rated operating current 4
A
8.5
15
19
Rated power consumption 4
kW
(kVA)
5.6 (5.9)
9.4 (10.2)
12.3 (13.0)
Noise level (Front: 1m, height: 1m)

4
dB(A)
75
75
71
Accessories
Operation manual (for installation/operation) (English 1, Japanese 1)
Particle filter set for CH1
Particle filter set for CH2
Anchor bracket 2pcs. (including 6 pcs. of M8 bolts) 7
Weight (in the dry state) 11
kg
Approx.240
Approx.260
Approx.330








