SMC Networks HRL100-A 40 Series User Manual

HRX-OM-X037
Chapter 9 Documents
9.5 Pump Capacity HRL Series
9-22
9.5.5 HRL100/200/300-A/W-40-T2 CH1
Fig. 9-27 Pump capacity(HRL100/200/300-A/W-40-T2 CH1)
9.5.6 HRL300-A-40-T3 CH2
Fig. 9-28 Pump capacity(HRL300-A-40-T3 CH2)
0
10
20
30
40
50
60
0
0.1
0.2
0.3
0.4
0.5
0.6
0 5 10 15 20 25 30 35
Lifting head [m]
Pressure[MPa]
Circulating fluid flow[L/min]
Usable flow rate
Circulating
fluidoutlet
Circulating
fluidreturn
0
10
20
30
40
50
60
0
0.1
0.2
0.3
0.4
0.5
0.6
0 10 20 30 40 50 60 70
Lifting head [m]
Pressure[MPa]
Circulating fluid flow[L/min]
Usable flow rate range
Circulating
fluidoutlet
Circulating
fluidreturn
