SMC Networks HRL100-A 40 Series User Manual

HRX-OM-X037
Chapter 9 Documents
9.5 Pump Capacity HRL Series
9-20
9.5 Pump Capacity
9.5.1 HRL100-A/W-40 CH1
Fig. 9-23 Pump capacity(HRL100-A/W-40 CH1)
9.5.2 HRL200-A/W-40 CH1
Fig. 9-24 Pump capacity(HRL200-A/W-40 CH1)
0
0.1
0.2
0.3
0.4
0.5
0.6
0 10 20 30 40 50 60 70 80 90 100 110 120
Circulating fluid flow [L/min]
Pressure [MPa]
0
10
20
30
40
50
60
Lifting head [m]
Usable flow
rate range
Circulating fluid
return
Circulating fluid
outlet
0
0.1
0.2
0.3
0.4
0.5
0.6
0 10 20 30 40 50 60 70 80 90 100 110 120 130
Circulating fluid flow [L/min]
Pressure [MPa]
0
10
20
30
40
50
60
Lifting head [m]
Usable flow rate range
Circulating fluid
return
Circulating fluid
outlet
