SMC Networks HRL100-A 40 Series User Manual

HRX-OM-X037
Chapter 3 Transport and Setting Up
3.1 Transport HRL Series
3-2
3.1.1 Transportation using forklift and hanging
Fig. 3-1 Fork inserting and hanging position (This drawing shows “HRL200-A-40”.)
Table 3.1-1 Weight of the product
Model
Weight kg
Option increase
HRL100-A-40
Approx.240
Option-D1:+1kg
Option-T2:+1kg
Option-T3:+18kg*
HRL200-A-40
Approx.260
HRL300-A-40
Approx.330
HRL100-W-40
Approx.250
HRL200-W-40
Approx.250
*Applicable only to HRL300-A*-40.
Fork inserting position
Position to hang
60°or less
Fork inserting position
This is a heavy product. (Refer to Table 3.1-1 Weight of the product)
Moving by forklift and slinging should be done by persons who have
the licenses.
