SMC Networks HRL100-A 40 Series User Manual

HRX-OM-X037
Chapter 3 Transport and Setting Up
3.3 Installation HRL Series
3-26
Fig. 3-13 RS-485 communication wiring
 Wiring of the interface communication cable
Dsub 9 female pin
(socket) type
5
1
9
6
Be sure to turn OFF the breaker of the facility power supply (the
user's machine power supply) before wiring.

SMC Networks HRL100-A 40 Series Specifications

General

Brand	SMC Networks
Model	HRL100-A 40 Series
Category	Chiller
Language	English
