HRX-OM-X037
Chapter 2 Name and Function of Parts
2.2 Name and Function of Parts HRL Series
2-4
Table 2.2-1 Accessory list

1 When “ F ” or “ N ” piping thread type is selected, the particle filter connection is “ G thread ” or “ NPT thread ”.
2 The anchor brackets are used for fixation with the skid when this product is packed. The anchor bolts are not
attached. The bolts (M8) used for fixing to the skid are not anchor bolts. Refer to "3.3.1 Installation" when using
anchor bolt fixing bracket.
(1)
Operation Manual
2 pcs.
(English 1 pc. /Japanese 1 pc.)
(2)
Particle filter set (for CH1) 1
1 set
(3)
Particle filter set (for CH2) 1
1 set
[For option –T3.]
(4)
For HRL-A/WF-
G thread adapter set
1 set
For HRL-A/WN-
NPT thread adapter set
1 set
(5)
Anchor brackets 2
2 pcs.
(6)
DI Filter
1 pc.
(7)
For option –D1.
DI Filter (for CH1)
1 pc.
