HRX-OM-X037
Chapter 3 Transport and Setting Up
HRL Series 3.2 Installation
3-7
 Required facility water system (for water cooled type)
Table 3-1 Heat Radiated
Model
Heat
Radiated
kW
Facility water specifications
HRL100-W*-40
Approx.18
Refer to “9.1 Specifications”.
HRL200-W*-40
Approx.35
 Installation environment specifications
Sound noise: HRL100-A-40 : 75 dB(A)
HRL200-A-40 : 75 dB(A)
HRL300-A-40 : 71 dB(A)
HRL100-W-40 : 72 dB(A)
HRL300-W-40 : 72 dB(A)
* Front 1m, height 1m, rated condition
The water cooled product radiates heat to the facility water.
It is necessary to supply the facility water. Please prepare the facility
water system that satisfies the heat radiation and the facility water
specifications below.
