HRX-OM-X037
Chapter 3 Transport and Setting Up
3.3 Installation
HRL Series
Use the adjuster foot
1. Install the product on a level floor.
2. Lower the adjuster to the level floor to fix the product in place.
Fig. 3-5 Installation by adjuster foot
Lower the adjuster to the level floor
to fix the product in place.
Install the product on a vibration free level floor.
Be sure to use the adjuster foot to install on the floor. The adjuster
foot is not earthquake-proof. If necessary make an
earthquake-resistant measure on the customer side.
