Subaru Forester 2004 - Page 14

AC-12
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)
General Description
• RHD MODEL WITH MANUAL A/C
(1) Upper case (4) Air inlet select link (7) Cover
(2) Air inlet select actuator (5) Filter cover (8) Lower case
(3) Air inlet select lever (6) Blower resister (9) Blower motor ASSY
AC-00085
(1)
(5)
(3)
(2)
(4)
(7)
(8)
(6)
(9)
