LI-2
LIGHTING SYSTEM
General Description
1. General Description
A: SPECIFICATION
B: PRECAUTIONS
• Before removing and installing parts, always disconnect the battery ground cable. When replacing audio,
control module, and other parts provided with memory functions, record memory contents before disconnect-
ing the battery ground cable. Otherwise, the memory will be erased.
• Reassemble in reverse order of disassembly, unless otherwise indicated.
• Adjust parts to the given specifications.
• Connect the connectors and hoses securely during reassembly.
• After reassembly, make sure functional parts operate smoothly.
WARNING:
• Airbag system wiring harness is routed near electrical parts and switches. All airbag system wiring
harnesses and connectors are yellow. Do not use electric test equipment on these circuits.
• Be careful not to damage the airbag system wiring harness when servicing electrical parts and
switches.
C: PREPARATION TOOL
1. GENERAL TOOL
Headlight 12 V — 55 W/60 W
Front turn signal light 12 V — 21 W
Clearance light 12 V — 5 W
Side marker light 12 V — 5 W
Front fog light 12 V — 55 W
Rear combination light
Tail/Stop light 12 V — 5/21 W
Turn signal light 12 V — 21 W
Back-up light 12 V — 16 W
License plate light 12 V — 5 W
High-mounted stop light
Standard type 12 V — 13 W
Rear spoiler built-in type 12 V — 1.2 W
Room light 12 V — 8 W
Spot light 12 V — 8 W
Luggage room light 12 V — 5 W
TOOL NAME REMARKS
Circuit tester Used for measuring resistance and voltage.
