Subaru Forester 2004 - Turn Signal Switch

LI-12
LIGHTING SYSTEM
Combination Switch (Light)
2. DIMMER AND PASSING SWITCH
LHD and RHD model with rear fog light:
RHD model without rear fog light:
3. TURN SIGNAL SWITCH
LHD and RHD with rear fog light:
RHD model without rear fog light:
4. PARKING SWITCH
Switch position Terminal No. Standard
Passing 7, 8 and 16 Less than 1 Ω
Low beam 16 and 17 Less than 1 Ω
High beam 7 and 16 Less than 1 Ω
Switch position Terminal No. Standard
Passing 1, 2 and 9 Less than 1 Ω
Low beam 9 and 10 Less than 1 Ω
High beam 2 and 9 Less than 1 Ω
Switch position Terminal No. Standard
Left 1 and 2 Less than 1 Ω
Neutral — More than 1 MΩ
Right 2 and 3 Less than 1 Ω
Switch position Terminal No. Standard
Left 6 and 7 Less than 1 Ω
Neutral — More than 1 MΩ
Right 7 and 8 Less than 1 Ω
Switch position Terminal No. Standard
OFF 2 and 4 Less than 1 Ω
ON 1 and 4 Less than 1 Ω
