SL-34
SECURITY AND LOCK
Remote Openers
16.Remote Openers
A: REMOVAL
1. HOOD OPENER
1) Remove the front hood lock assembly. <Ref. to
SL-33, REMOVAL, Front Hood Lock Assembly.>
2) Remove the release cable from hood lock.
3) Remove the bolt. Remove the opener lever.
2. FUEL FLAP OPENER
1) Remove the rear seat. <Ref. to SE-13, REMOV-
AL, Rear Seat.>
2) Remove the center pillar lower trim and side sill
cover. Remove the rear pillar lower trim. Pull back
the floor mat.
3) Remove the right rear quarter trim. <Ref. to EI-
45, REMOVAL, Rear Quarter Trim.>
Remove the clip holding the cable.
4) Remove the bolt. Remove the opener pull han-
dle.
5) Remove the cable (A) from opener pull handle
(B).
6) Rotate the fuel lock inside the quarter panel to
left and remove.
B: INSTALLATION
1. HOOD OPENER
Install in the reverse order of removal.
2. FUEL FLAP OPENER
Install in the reverse order of removal.
C: INSPECTION
Make sure the fuel flap opens and closes smoothly.
SL-00038
SL-00022
SL-00023
