LI-27
LIGHTING SYSTEM
High-mounted Stop Light
23.High-mounted Stop Light
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the cap (a) by prying on the edge with
screwdriver.
3) Remove the screws (b), and then detach the
cover (c).
4) Remove the screws (d), disconnect the connec-
tor, and then detach the high-mounted stop light.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. <Ref. to LI-2, SPEC-
IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00036
(d)
(c)
(a)
(b)
