Subaru Forester 2004 - Upper Inner Trim

EI-43
EXTERIOR/INTERIOR TRIM
Upper Inner Trim
17.Upper Inner Trim
A: REMOVAL
1) Remove the lower inner trim. <Ref. to EI-44, RE-
MOVAL, Lower Inner Trim.>
2) Remove the front molding (A).
3) Remove the front pillar upper trim (B).
4) Detach the front seat belt shoulder anchor, then
remove the center pillar upper trim (C).
B: INSTALLATION
Install in the reverse order of removal.
CAUTION:
Be sure to securely hook pawls of inner trim
panel to body flange.
NOTE:
When installing the center pillar upper trim and front
pillar upper trim, be sure to set the front molding as
shown in the figure.
(D) Clip
(A) Outside
(B) Inside
(C) Molding
(D) Weather strip
(E) Trim
(F) Body
EI-00105
(A)
(B)
(C)
: (D)
EI-00106
(A)
(C)
(B)
(E)
(F)
(D)
