SL-28
SECURITY AND LOCK
Rear Door Latch Assembly
10.Rear Door Latch Assembly
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the rear door trim. <Ref. to EI-36, RE-
MOVAL, Rear Door Trim.>
3) Remove the sealing cover. <Ref. to EB-16, RE-
MOVAL, Rear Sealing Cover.>
4) Remove the rear inner remote. <Ref. to SL-26,
REMOVAL, Rear Inner Remote.>
5) Remove the three screws and bolt.
6) Remove the rear door latch assembly, and then
disconnect the connector.
B: INSTALLATION
Install in the reverse order of removal.
NOTE:
Make sure the lock works properly after installation.
C: INSPECTION
1) Make sure the cable is not deformed.
2) Make sure the lever and cable work smoothly.
SL-00014
