GW-8
GLASS/WINDOW/MIRROR
Power Window Control Switch
C: INSPECTION
1. MAIN SWITCH
Measure the switch resistance.
• LHD model
If NG, replace the main switch.
Switch position Terminal No. Standard
Driver’s side
AUTO UP 13 and 2, 1 and 5 Less than 1 Ω
UP 13 and 2, 1 and 5 Less than 1 Ω
OFF
1 and 2
1 and 5
2 and 5
Less than 1 Ω
DOWN 13 and 1, 2 and 5 Less than 1 Ω
AUTO DOWN 13 and 1, 2 and 5 Less than 1 Ω
Front passenger’s side
UP 13 and 7, 6 and 5 Less than 1 Ω
OFF
5 and 6
5 and 7
6 and 7
Less than 1 Ω
DOWN 13 and 6, 7 and 5 Less than 1 Ω
Rear LH
UP 10 and 13, 11 and 5 Less than 1 Ω
OFF
5 and 11
5 and 10
11 and 10
Less than 1 Ω
DOWN 13 and 11, 10 and 5 Less than 1 Ω
Rear RH
UP 13 and 15, 16 and 5 Less than 1 Ω
OFF
5 and 15
5 and 16
15 and 16
Less than 1 Ω
DOWN 13 and 16, 15 and 5 Less than 1 Ω
