GW-22
GLASS/WINDOW/MIRROR
Rear Door Glass
11.Rear Door Glass
A: REMOVAL
1) Remove the rear door trim. <Ref. to EI-36, RE-
MOVAL, Rear Door Trim.>
2) Remove the front speaker. <Ref. to ET-6, RE-
MOVAL, Front Speaker.>
3) Remove the sealing cover. <Ref. to EB-16, RE-
MOVAL, Rear Sealing Cover.>
4) Remove the stabilizer.
5) Remove the door weather strip.
6) Loosen the two screws to remove the weather
strip outer.
7) Operate the power window switch to remove glass
as shown in the figure, and then remove two nuts.
8) Take out the door glass.
CAUTION:
Avoid impact and damage to the glass.
GW-00030
GW-00057
GW-00032
GW-00031
To Next Page
