Subaru Forester 2004 - Neutral Position Switch (MT Model)

CC-13
CRUISE CONTROL SYSTEM
Neutral Position Switch (MT model)
9. Neutral Position Switch (MT
model)
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Disconnect the connector from neutral position
switch, and then remove the switch. <Ref. to 5MT-
43, BACK-UP LIGHT AND NEUTRAL POSITION
SWITCH, REMOVAL, Switches and Harness.>
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
Measure the neutral position switch resistance.
• Non-turbo model
• Turbo model
If NG, replace the neutral position switch.
Gear shift position Terminal No. Specified resistance
Neutral position
1 and 2
Less than 1 Ω
Other positions More than 1 MΩ
Gear shift position Terminal No. Specified resistance
Neutral position
1 and 3
Less than 1 Ω
Other positions More than 1 MΩ
MT-00110
12
MT-00111
12
34
