Rear Window Defogger System
16.Rear Window Defogger System
A: WIRING DIAGRAM
1. REAR WINDOW DEFOGGER
<Ref. to WI-251, WIRING DIAGRAM, Rear Window Defogger System.>
B: INSPECTION
Symptom Repair order
Rear window defogger does not operate.
(1) Fuse (M/B No. 1) (F/B No. 17)
(2) Rear defogger relay
(3) Rear defogger timer
(4) Defogger switch
(5) Rear defogger condenser
(6) Defogger wire
(7) Wiring harness
