LI-19
LIGHTING SYSTEM
Front Fog Light Assembly
15.Front Fog Light Assembly
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the two clips and lower mudguard.
3) Disconnect the harness connector.
4) Remove the lower bolts.
5) Remove the mounting bolts and clip, and then
detach the fog light assembly.
B: INSTALLATION
Install in the reverse order of removal.
LI-00023
LI-00024
LI-00025
