COM-4
COMMUNICATION SYSTEM
Horn
3. Horn
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the front fog light assembly (LH). <Ref.
to LI-19, REMOVAL, Front Fog Light Assembly.>
3) Remove the horn bracket mounting bolt (A).
4) Disconnect the harness connector and remove
the horn assembly (B).
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
With 12 V direct current supplied between horn ter-
minal and case ground, check that the horn sounds
properly.
COM00002
(B)
(A)
COM00003
