GW-12
GLASS/WINDOW/MIRROR
Outer Mirror Assembly
6. Outer Mirror Assembly
A: REMOVAL
1) Remove the door trim. <Ref. to EI-35, REMOV-
AL, Front Door Trim.>
2) Remove the mirror gusset cover.
3) Disconnect the mirror connector.
4) Remove the grommet, and then loosen the
screws to remove mirror assembly.
B: INSTALLATION
Install in the reverse order of removal.
(1) Hook
: (1)
GW-00061
GW-00010
