CC-8
CRUISE CONTROL SYSTEM
Cruise Control Main Switch
4. Cruise Control Main Switch
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the screws and clip from instrument
panel lower cover.
3) Remove the instrument panel lower cover.
4) Disconnect the connector from cruise control
main switch.
5) Remove the main switch by pushing it outward.
• For Europe model
• For Australia model
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
Measure the cruise control main switch resistance.
If NG, replace the cruise control main switch.
CC-00014
CC-00015
CC-00071
CC-00072
Switch position Terminal No. Standard
OFF (released)
LHD, RHD (For
Europe) model : 1
and 2
More than 1 MΩ
ON (depressed)
RHD (Except for
Europe) model : 3
and 5
Less than 1 Ω
CC-00073
12
64
53
