GW-10
GLASS/WINDOW/MIRROR
Remote Control Mirror System
4. Remote Control Mirror System
A: WIRING DIAGRAM
1. REMOTE CONTROL MIRROR
<Ref. to WI-253, WIRING DIAGRAM, Remote Controlled Rearview Mirror System.>
B: INSPECTION
Symptom Repair order
All function does not operate.
(1) Fuse (F/B No. 4) (F/B No. 13) (F/B No. 17) (F/B No. 18)
(2) Mirror switch
(3) Wiring harness
One side of the mirror motor does not operate.
(1) Mirror switch
(2) Mirror motor
(3) Wiring harness
Heated mirror does not operate.
(1) Mirror switch
(2) Heated mirror
(3) Wiring harness
