AC-14
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)
General Description
• LHD MODEL WITH MANUAL A/C
(1) Panel (5) A/C switch (9) Mode control cable
(2) Temperature control dial (6) Air inlet select switch (10) Temperature control cable
(3) Fan dial (7) Rear defogger switch (11) Bulb
(4) Mode control dial (8) Switch circuit board
AC-00211
(2)
(6)
(5)
(7)
(4)
(3)
(1)
(8)
(10)
(9)
(11)
